AMD Ryzen 7 5700, 8-Core/16 Threads Socket AM4 65W CPU Overview

36 months

Specifications


Platform Boxed Processor
Market Segment Mainstream Desktop
Product Family AMD Ryzen™ Processors
Product Line AMD Ryzen™ 7 Desktop Processors
Consumer Use Yes
Regional Availability Global, China, NA, EMEA, APJ, LATAM
Former Codename "Cezanne"
Architecture "Zen 3"
Number of CPU Cores 8
Number of Threads 16
Max. Boost Clock Up to 4.6GHz
Base Clock 3.7GHz
L1 Cache 512KB
L2 Cache 4MB
L3 Cache 16MB
Default TDP 65W
AMD Configurable TDP (cTDP) 45-65W
Processor Technology for CPU Cores TSMC 7nm FinFET
CPU Compute Die (CCD) Size 180mm²
Package Die Count 1
Unlocked for Overclocking Yes
CPU Socket AM4
Socket Count 1P
Supporting Chipsets X570
X470
X370
B550
B450
B350
A520
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Thermal Solution (PIB) AMD Wraith Stealth
Max. Operating Temperature (Tjmax) 95°C
Launch Date 4/4/2022
OS Support Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support Yes
Native USB 4 (40Gbps) Ports 0
Native USB 3.2 Gen 2 (10Gbps) Ports 4
Native USB 3.2 Gen 1 (5Gbps) Ports 0
Native USB 2.0 (480Mbps) Ports 0
Native SATA Ports 2
PCI Express® Version PCIe 3.0
Native PCIe® Lanes (Total/Usable) 24 / 20
Additional Usable PCIe Lanes from Motherboard AMD X570 16x Gen 3
AMD X470 2x Gen 3
AMD X470 8x Gen 2
NVMe Support Boot, RAID0, RAID1, RAID10
System Memory Type DDR4
Memory Channels 2
System Memory Subtype UDIMM
System Memory Specification Up to 3200MT/s
Max Memory Speed 2x1R DDR4-3200
2x2R DDR4-3200
4x1R DDR4-2933
4x2R DDR4-2667
ECC Support No
Graphics Capabilities
Integrated Graphics No
Graphics Model Discrete Graphics Card Required
Product IDs
Product ID Boxed 100-000000743BOX
Product ID Tray 100-000000743
Product ID MPK 100-000000743MPK
Key Features
Supported Technologies AMD StoreMI Technology
AMD Ryzen™ VR-Ready Premium
SKU CPAR7-5700
Brand AMD
Unit Of Measure ea
