AMD Ryzen 5 9600X 6Cores/12Threads, 65 watt CPU  Overview

36 months

Specifications

General Specifications
Name AMD Ryzen™ 5 9600X
Family Ryzen
Series Ryzen 9000 Series
Form Factor Desktops , Boxed Processor
Market Segment Enthusiast Desktop
AMD PRO Technologies No
Consumer Use Yes
Regional Availability Global
Former Codename Granite Ridge AM5
Architecture Zen 5
# of CPU Cores 6
Multithreading (SMT) Yes
# of Threads 12
Max. Boost Clock  Up to 5.4 GHz
Base Clock  3.9 GHz
L1 Cache 480 KB
L2 Cache 6 MB
L3 Cache 32 MB
Default TDP 65W
Processor Technology for CPU Cores TSMC 4nm FinFET
Processor Technology for I/O Die TSMC 6nm FinFET
Package Die Count 2
Unlocked for Overclocking  Yes
AMD EXPO™ Memory Overclocking Technology Yes
Precision Boost Overdrive Yes
Curve Optimizer Voltage Offsets Yes
AMD Ryzen™ Master Support Yes
CPU Socket AM5
Supporting Chipsets A620 , X670E , X670 , B650E , B650 , X870E , X870
CPU Boost Technology Precision Boost 2
Instruction Set x86-64
Supported Extensions AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Thermal Solution (PIB) Not Included
Recommended Cooler Premium air cooler recommended for optimal performance
Max. Operating Temperature (Tjmax) 95°C
*OS Support Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Connectivity
Native USB 3.2 Gen 2 (10Gbps) Ports 4
Native USB 2.0 (480Mbps) Ports 1
PCI Express® Version PCIe® 5.0
Native PCIe® Lanes (Total/Usable) 28 , 24
Additional Usable PCIe Lanes from Motherboard X870E 8x Gen4
  X870 4x Gen4
  X670E 12x Gen4
  X670 12x Gen4
  B650E 8x Gen4
  B650 8x Gen4
NVMe Support Boot , RAID0 , RAID1 , RAID5 , RAID10
System Memory Type DDR5
Memory Channels 2
Max. Memory 192 GB
System Memory Subtype UDIMM
Max Memory Speed 2x1R DDR5-5600
  2x2R DDR5-5600
  4x1R DDR5-3600
  4x2R DDR5-3600
ECC Support Yes (Requires mobo support)
Graphics Capabilities
Graphics Model AMD Radeon™ Graphics
Graphics Core Count 2
Graphics Frequency 2200 MHz
USB Type-C® DisplayPort™ Alternate Mode Yes
Product IDs
Product ID Boxed 100-100001405WOF
Product ID Tray 100-000001405
Key Features
Supported Technologies AMD EXPO™ Technology , AMD Ryzen™ Technologies
SKU CPAR5-9600X
Brand AMD
Unit Of Measure ea
