ASUS PRIME B650-PLUS AMD AM5 ATX Motherboard

ASUS PRIME B650-PLUS AMD AM5 ATX Motherboard





36 months

  • Compatible Ryzen 7 processor lets you perform all your computational tasks at a swift pace
  • DDR5 SDRAM slot for convenient installation of memory
  • Supported 0 RAID levels provide data reliability and fault tolerance
  • HDMI interface connects the top of the line PCs, Blu-ray players, and cutting edge Gaming Controllers
  • DisplayPort transmits both audio and video signals through a common channel to deliver versatile performance
  • Features Thunderbolt I/O that lets you move data between your devices and computers with unprecedented speed
  • ATX form factor brings a significant number of PCI slots, expansion slots, and peripheral ports with an enhanced heat dissipation capability
  • With 2 USB 2.0 ports, transfer several documents without error

Technical Specs

Audio

Audio Channels 7.1

Miscellaneous

Brand Compatibility AMD

Video

Onboard Video CPU Dependent Video

Network & Communication

Gigabit Ethernet Yes
2.5Gigabit Ethernet Yes

Physical Characteristics

Form Factor ATX
Width 304.8 mm
Depth 243.8 mm

Onboard Interfaces

Number of SATA Interfaces 4
Total Number of Onboard USB Ports 7
Number of Onboard USB 2.0 Ports 4
Number of M.2 Interfaces 2

I/O Controller

RAID Levels 10
1
0
Controller Type Serial ATA/600
RAID Supported Yes

I/O Expansions

Number of PCI Express x1 Slots 2
Number of Total Expansion Slots 4
Number of PCI Express x16 Slots 2
PCI Express Standard PCI Express 4.0
Total Number of PCI Express Slots 4

Interfaces/Ports

S/PDIF Yes
HDMI Yes
HDMI Version 2.1
Number of Network (RJ-45) Ports 1
DisplayPort Yes
Total Number of USB Ports 8
Number of USB 2.0 Ports 2
Thunderbolt Yes
Number of USB 3.2 Ports 6
Number of USB 3.2 Gen 2 Type-C Ports 1
Number of USB 3.2 Gen 1 Type-A Ports 2
Number of USB 3.2 Gen 2 Type-A Ports 3
Number of Thunderbolt 4 Ports 1

Processor & Chipset

Processor Supported Ryzen 7
Total Processor Supported 1
Processor Socket Socket AM5
Chipset Manufacturer AMD
Chipset Model B650

General Information

Product Type Desktop Motherboard
Manufacturer Part Number PRIME B650-PLUS
Manufacturer Website Address http://www.asus.com/au
Manufacturer ASUS Computer International
Product Model B650-PLUS
Product Name Prime B650-PLUS Desktop Motherboard
Product Line Prime
Product Series B650
Brand Name Asus

Memory

Maximum Memory Supported 128 GB
Memory Technology DDR5 SDRAM
Number of Memory Slots 4
Memory Form Factor DIMM
UDIMM
Memory Speed Supported 5600 MHz
5400 MHz
4800 MHz
6400 MHz
6200 MHz
6000 MHz
5800 MHz
5200 MHz
5000 MHz
SKU MBB650-PLUS
Brand ASUS
Unit Of Measure ea
